Panasonic 8.0/9.0kW Split Reverse Inverter Air Conditioner and Air Purifier

Model CS/CU-Z80YKR
IPN 830244
Panasonic
$ PRICE MATCH GUARANTEE

We'll match a local competitor's advertised price on the same product. Contact us for details!

1 1
Panasonic

Panasonic 8.0/9.0kW Split Reverse Inverter Air Conditioner and Air Purifier

Model CS/CU-Z80YKR
IPN 830244
$ PRICE MATCH GUARANTEE

We'll match a local competitor's advertised price on the same product. Contact us for details!

$2,799
BEFORE
NOW $2,799
PHONE SALES 1300 863 749

Check Availability

Enter your location in the field below to get delivery estimates and stock information for your local store.

Overview
Delivery & Returns
Payment Options
Reviews

Overview

description

The Panasonic 8.0/9.0kW Split Reverse Cycle Inverter Air Conditioner with Air Purifier delivers powerful climate control with advanced air purification for year-round comfort. Providing 8.0kW of cooling and 9.0kW of heating, it is ideal for large living spaces and open-plan areas. The new compact indoor unit offers a sleek design while allowing easier installation and servicing. Featuring 24-hour Nanoe-X air purification, it helps reduce odours, allergens, and airborne pollutants for a healthier indoor environment. Built-in Wi-Fi with smart control enables convenient remote operation from a compatible device. With strong energy efficiency ratings of 3.5 stars across hot, average, and cold climates for cooling, and up to 3.5 stars for heating, this Panasonic system combines performance, efficiency, and intelligent comfort.

specifications

  • Brand
    Panasonic
  • IPN
    830244
  • Model
    CS/CU-Z80YKR
  • Manufacturer's Warranty
    5 Years
  • Size
    8.0/9.0kW
  • Width
    1040.0
  • Height
    295.0
  • Depth
    244 mm
  • Colour/Finish
    WHITE
  • Indoor unit
    CS-Z80YKR
  • Outdoor unit
    CU-Z80YKR
  • Cooling Capacity (min-max) (kW)
    8.00 (2.30-9.00) kW
  • Heating Capacity (min-max) (kW)
    9.00 (2.20-11.60) kW
  • Cooling Capacity (min-max) (Btu/h)
    27,300 (7,840-30,700) Btu/h
  • Heating Capacity (min-max) (Btu/h)
    30,700 (7,500-39,600) Btu/h
  • Cooling Indoor Air Flow (L/s)
    367 L/s
  • Heating Indoor Air Flow (L/s)
    377 L/s
  • Dehumid (L/h)
    4.70 L/h
  • Cooling Running Current (A)
    10.10 A
  • Heating Running Current (A)
    9.80 A
  • Max Current (A)
    15.00 A
  • Cooling Power Input (min-max) (kW)
    2.39 (0.46-3.03) kW
  • Heating Power Input (min-max) (kW)
    2.34 (0.43-3.42) kW
  • Cooling AEER/EER
    3.43 W/W / 3.35 W/W
  • Heating ACOP/COP
    3.83 W/W / 3.85 W/W
  • Star Rating Residential/Commercial - Cooling (Hot Climate)
    3.5/4.5 TCSPF
  • Star Rating Residential/Commercial - Cooling (Average Climate)
    3.5/5.0 TCSPF
  • Star Rating Residential/Commercial - Cooling (Cold Climate)
    3.5/6.0 TCSPF
  • Star Rating Residential/Commercial - Heating (Hot Climate)
    3.5/3.5 HSPF
  • Star Rating Residential/Commercial - Heating (Average Climate)
    2.5/3.0 HSPF
  • Star Rating Residential/Commercial - Heating (Cold Climate)
    2.0/2.5 HSPF
  • Indoor Unit Sound Pressure Noise Level (Cooling) (H / L / Q-Lo)
    51/38/35 dB(A) *Sound pressure level specification is measured accroding to JIS C9612
  • Indoor Unit Sound Pressure Noise Level (Heating) (H / L / Q-Lo)
    50/38/35 dB(A) *Sound pressure level specification is measured accroding to JIS C9612
  • Indoor Unit Sound Power Noise Level (Cooling) (H / L / Q-Lo)
    67/54/51 dB(A)
  • Indoor Unit Sound Power Noise Level (Heating) (H / L / Q-Lo)
    66/54/51 dB(A)
  • Outdoor Unit Sound Pressure Noise Level (Cooling) (H / Q-Lo)
    55/50 dB(A) *Sound pressure level specification is measured accroding to JIS C9612
  • Outdoor Unit Sound Pressure Noise Level (Heating) (H / Q-Lo)
    55/50 dB(A) *Sound pressure level specification is measured accroding to JIS C9612
  • Outdoor Unit Sound Power Noise Level (Cooling) (H / Q-Lo)
    69/64 dB(A)
  • Outdoor Unit Sound Power Noise Level (Heating) (H / Q-Lo)
    69/64 dB(A)
  • Refrigerant Type
    R32
  • Refrigerant Pipe Diameter (Liquid Side)
    ø 6.35 mm (1/4 inch)
  • Refrigerant Pipe Diameter (Gas Side)
    ø 15.88 mm (5/8 inch)
  • Pipe Extension Length (min-max)
    3 m ~ 30 m
  • Maximum Elevation Length
    20 m
  • Pipe Length for Additional Refrigerant Gas
    10 m
  • Additional Gas Amount
    25 g/m
  • Power Supply
    Outdoor
  • Outdoor Unit Operating Range (Cooling)
    -10°C ~ +46°C
  • Outdoor Unit Operating Range (Heating)
    -15°C ~ +24°C
  • iAUTO-X
    Yes
  • ECO Mode with A.I.
    Yes
  • Inverter Control
    Yes
  • Sleep Mode
    Yes
  • Quiet Mode
    Yes
  • Fan Mode
    Yes
  • Soft Dry Operation Mode
    Yes
  • Hot Start Control
    Yes
  • Auto Changeover (Inverter)
    Yes
  • Personal Airflow Creation
    Yes
  • Manual Horizontal Airflow Direction Control
    No
  • Airflow Direction Control (Up & Down)
    No
  • nanoe™ X
    Yes (Generator Mark 1)
  • Odour Removing Function
    Yes
  • Removable Washable Panel
    Yes
  • 24-Hour Dual ON & OFF Real Setting Timer
    Yes
  • Demand Response Enabling Device (DRED)
    Yes
  • LCD Wireless Remote Control
    Yes
  • Wi-Fi
    Yes (Built-in)
  • Wired Remote Control
    Yes (Optional)
  • Random Auto Restart
    Yes (32 Restart Patterns)
  • Blue Fin Condenser
    Yes
  • Long Piping (max.)
    30 m
  • Top Panel Maintenance Access
    Yes
  • Self-Diagnostic Function
    Yes

features

rating

  • nanoe™ X 24-hour air purification
  • Built-in Wi-Fi
  • Comfort Cloud App
  • iAUTO-X Mode
  • AEROWINGS
  • ECO Mode with A.I. control
  • Energy efficiency with Inverter technology
  • R32 refrigerant
